Coping slabs Share

Coping slabs are bent to measure from aluminium sheet provided with a protective film.

Alloy

Al Mg 1

Quality

AG 06 - 5005 - 1/2 hard AOD

Thickness

2 mm

Length

3000 mm

Shape

Vertical sides:

• model 1 (horizontal surface) minimum h: 50 mm with concrete-form plywood 70 mm

Width

wall thickness + 60 mm
Brackets made of extruded hardened aluminium, width: 100 mm, thickness: 2 mm, with ribbed strips. The rot-free PVC foam rubber strips insulate the brace of the cover plate. Joint covers made of bent aluminium, 100 mm wide.
